Place of Origin:
Shaanxi, China
Brand Name:
Hoan
Certification:
ISO9001:2015
Model Number:
JZP-10.5
Video
JZP Series
The JZP-10.5 isolator is widely used in many key areas due to its excellent performance. In the precision instrument manufacturing industry, it can provide a stable working environment for high-precision processing equipment, effectively reduce the interference of external vibration on machining accuracy, and ensure high-quality output of products. In the field of shipbuilding, whether it is to resist the impact of waves when the ship is sailing, or in the operation and shock absorption of the ship's internal equipment, the JZP-10.5 shock absorber plays an irreplaceable role. In the equipment installation of the communication base station, it can absorb the small vibrations generated by the operation of the equipment, ensure the stable operation of the communication equipment, reduce the interference and fluctuation of signal transmission, and maintain the efficiency and reliability of the communication network.
With the continuous progress of science and technology and the continuous growth of industrial demand, JZP-10.5 shock absorber is also constantly undergoing technological innovation and optimization. By adopting new materials, optimizing structural design and introducing advanced intelligent control technology, R&D personnel further improve its buffering performance, reliability and adaptability, so as to meet the requirements of more stringent industrial application scenarios and technical standards in the future, and continue to contribute to the development process of various industries
Performance parameters
| Model |
Nominal load (kg) |
Static displacement (mm) |
Operating temperature (℃) |
Resonant frequency (Hz) |
Damping ratio | Impact experiments | expiration date | Expiration date |
| JZP-2.5 | 2.5 | ≤0.3 | -45～+65 | 41.5±5 | ≥0.13 | 100g12次 | 8 | 5 |
| JZP-3.2 | 3.2 | |||||||
| JZP-4.2 | 4.2 | |||||||
| JZP-5.2 | 5.2 | |||||||
| JZP-6.0 | 6.0 | |||||||
| JZP-7.0 | 7.0 | |||||||
| JZP-7.5 | 7.5 | |||||||
| JZP-8.5 | 8.5 | |||||||
| JZP-10.5 | 10.5 | |||||||
| JZP-13.5 | 13.5 | |||||||
| JZP-15 | 15 |
* Unique Characteristics of Xi'an Hoan's Vibration Isolators *
* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays
