JZP-7.5 Cable Vibration Isolators Customizable for Complex Working Environments

JZP Series

JZP-7.5 shock absorber is an excellent spare part in the industrial field, it has unique performance advantages, and can show different cushioning characteristics according to actual needs in a variety of complex working environments and conditions.

Since the 80s of the 20th century, vibration damping device technology has gradually been promoted and applied in various large-scale machinery, construction engineering and transportation fields. In the lifting operation of large cranes, shock absorbers can effectively reduce the impact force during the lifting and landing of goods, and ensure the stability and safety of lifting. In the track system of high-speed trains, the vibration damping device plays a vital role in the vibration absorption of the train during driving and the connection stability between the carriages, which greatly improves the riding comfort of passengers and reduces the wear and tear of track and vehicle components.

In mechanical structures, factors such as the clearance of the connecting parts, the surface roughness and the changes in the load they are subjected to can have a significant impact on the cushioning effect of the buffer. For example, at the joint connection of some heavy machinery, the temporary connection structure may produce different degrees of friction and deformation due to the running-in between parts in the early stage of equipment operation, and these changes will be directly fed back to the dynamic operation stability of the entire mechanical system. Although the permanent connection structure is relatively stable, the internal stress distribution will also change during long-term high-load operation, which will affect the working efficiency of the buffer.

Due to the interweaving of factors such as force transfer, energy conversion and material deformation involved in mechanical motion, it is a great challenge to accurately model the friction phenomenon and mechanical behavior in buffer structures. The friction during the buffering process is not constant, but can change in complexity with changes in conditions such as relative velocity, pressure, and temperature of the contact surface. At the same time, the description of the stress-strain state of the buffer component under force also needs to consider many factors such as the nonlinear properties of the material, the complexity of the geometry, and the uncertainty of the boundary conditions.

Performance parameters

* Unique Characteristics of Xi'an Hoan's Vibration Isolators *

* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays
