Place of Origin:
Shaanxi, China
Brand Name:
Hoan
Certification:
ISO9001:2015
Model Number:
JZP-1.0B-SC
JZP-B-SC Series
In the complex environment of modern industry and buildings, vibration and noise have become the key factors affecting the stable operation of equipment, structural safety and people's living comfort. The advent of prefabricated vibration isolators (JZPs) provides an efficient and reliable solution to solve these problems.
The core components of a fabricated isolator typically include materials such as springs and damping pads. As the main elastic support element, the spring can use its elastic deformation to absorb and cushion the vibration energy generated by the operation of the equipment or external factors. Different types of springs, such as coil springs, disc springs, etc., have their own unique mechanical properties, which can be selected according to actual working conditions. Shock-absorbing pads are generally made of rubber, polyurethane and other materials with good damping properties, which can further reduce the transmission of vibration waves, and at the same time effectively block the noise transmission path caused by vibration.
In terms of building structures, whether high-rise buildings or industrial plants, different degrees of structural vibration and noise propagation may occur when they are subjected to wind loads, seismic actions, or internal equipment vibrations. JZP can be installed in the foundation of the building or between the floors, effectively reducing the impact of vibration on the building structure, reducing the risk of structural fatigue damage, and reducing the indoor noise level, creating a quiet and comfortable environment for occupants and users, and improving the quality and safety of the building.
Product dimensions
| Series |
D (mm) |
H±1 (mm) |
h (mm) |
A±0.2 (mm) |
B (mm) |
d | d2 | R |
b (mm) |
h1 (mm) |
| JZP-B-SC | 46 | 30 | 21 | 40 | 50 | M4 | Φ5.5 | 5 | 22 | 3.5 |
Technical parameters
| Model |
Pz Nominal (Kg) |
Static displacement (mm) |
Operating temperature (℃) |
Resonant frequency (Hz) |
Damping ratio | Impact test | Expiration date |
| JZP-1.0B-SC | 1.0 | ≤0.3 | -45～+65 | 41.5±5 | ≥ | 100G12次 | 5 |
| JZP-1.5B-SC | 1.5 | ||||||
| JZP-2.0B-SC | 2.0 | ||||||
| JZP-2.5B-SC | 2.5 | ||||||
| JZP-3.0B-SC | 3.0 | ||||||
| JZP-3.5B-SC | 3.5 | ||||||
| JZP-4.0B-SC | 4.0 | ||||||
| JZP-5.0B-SC | 5.0 | ||||||
| JZP-5.5B-SC | 5.5 | ||||||
| JZP-6.0B-SC | 6.0 |
* Unique Characteristics of Xi'an Hoan's Vibration Isolators *
* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays
Equipment experiments
