Place of Origin:
Shaanxi, China
Brand Name:
Hoan
Certification:
ISO9001:2015
Model Number:
JZP-3.0C
JZP-C Series
JZP is mainly composed of springs, shock-absorbing pads and other materials, which seems to be an ordinary combination but contains strong vibration isolation and noise reduction capabilities. Like a skilled craftsman, it can be designed and installed according to different needs, and is used in a wide range of fields such as machinery, building structures, bridges and railway tracks.
In the field of machinery and equipment, industrial equipment and various types of machinery often produce vibrations and noise during operation. JZP is like a miracle doctor, treating these conditions with precision. It effectively reduces vibration and noise transmission, making the device feel like it is in a quiet and stable small world. The improvement of equipment stability directly brings about the improvement of work efficiency. For those high-precision machining equipment, the role of JZP is irreplaceable. It guarantees the precision of processing and makes the product quality to a higher level.
In terms of building structure, JZP has demonstrated strong earthquake and wind resistance. External vibrations, such as earthquakes and wind, threaten the safety of building structures and the comfort of occupants. However, the JZP acts as a strong shield to reduce the effects of these external vibrations. When an earthquake strikes, buildings with JZP are better able to maintain their structural integrity and provide safer shelter for people. At the same time, it can also protect the residents in the building from the discomfort caused by excessive shaking, which greatly improves the seismic performance and comfort of the building.
The advantages and characteristics of JZP are also an important reason why it is favored. The first is its flexibility. Just like a custom premium gown, JZP can be custom designed and installed according to specific needs. Whether it's a large industrial plant, a complex building structure or a long railway track, it is perfectly suited. The second is high efficiency, and when it comes to isolating vibration and noise, JZP has an excellent performance. It allows equipment, buildings or vehicles to operate in a relatively stable environment, improving the stability and comfort of operation. Finally, there is the economy, which is lower than the traditional vibration isolation method. And it is easy to install and maintain, which is undoubtedly a boon for cost and time savings for engineering construction.
Technical parameters
| Technical Parameter | JZP-0.3C | JZP-0.5C | JZP-0.8C | JZP-1.0C | JZP-1.2C | JZP-1.5C | JZP-1.8C | JZP-2.0C | JZP-2.5C | JZP-3.0C |
| Pz Nominal Load (Kg) | 0.3 | 0.5 | 0.8 | 1.0 | 1.2 | 1.5 | 1.8 | 2.0 | 2.5 | 3.0 |
| Deflection | Downward Pressure | |||||||||
| Deformation Displacement(mm) | ≤0.3 | |||||||||
| Resonant Frequency(Hz) | 35±3 | |||||||||
| Working Temperature(℃) | -45～+65 | |||||||||
| Shock(Ks) | 100g/6ms | |||||||||
| Peak Response(G) | ≤3.6km/s2 | |||||||||
| Vibration(Kv) | Accord with National Military Standard GJB150-16 | |||||||||
* Unique Characteristics of Xi'an Hoan's Vibration Isolators *
* No creep or ageing.
* High internal damping.
* Very wide temperature range.
* Wide variety of possible fittings.
* Rapid and economical prototyping.
* Extremely rugged construction and long lifespan.
* Excellent combined shock and vibration isolation.
* Not affected by chemical agents, seawater, ozone, UV rays
