Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber

Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber

Unmatched Performance Rubber Shock Absorber

Versatility Rubber Shock Absorber

JMZ-TK1-50 Rubber Shock Absorber

Place of Origin:

Shaanxi, China

Brand Name:

Hoan

Certification:

ISO9001:2015

Model Number:

JMZ-TK1-50

Contact Us

Request A Quote

Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber

Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber

Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber

Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber

Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber

Product Details

Installation Type:

Horizontal/Vertical

Mounting Orientation:

Vertical

Certifications:

ISO 9001:2015

Mounting Thread Size:

M10

Strand Construction:

7 X 19

Relative Product:

Backdraft Damper

Installation Method:

Horizontal

Model:

JMZ

Wire Diameter:

0.5mm

Length:

6 Inches

Height:

50mm

Working Temperatu:

: -55 ~ +120

Marketing Type:

New Product 2024

Compression Ratio:

1.2:1

Highlight:

Unmatched Performance Rubber Shock Absorber

,

Versatility Rubber Shock Absorber

,

JMZ-TK1-50 Rubber Shock Absorber

Payment & Shipping Terms

Minimum Order Quantity

4 piences

Delivery Time

7

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

4，pience，7

RELATED PRODUCTS

Good price Customized JZP-2.0C Rubber Shock Absorber for Machinery and Structural Protection in Various Applications online

Video

Customized JZP-2.0C Rubber Shock Absorber for Machinery and Structural Protection in Various Applications

Get Best Price

Good price JZP-1.8C The Top-Notch Rubber Shock Absorber for Vibration and Noise Reduction online

Video

JZP-1.8C The Top-Notch Rubber Shock Absorber for Vibration and Noise Reduction

Get Best Price

Good price JZP-1.0B-SC and Rubber Shock Absorber for Vibration and Noise Control in Wind Loads Seismic Actions and Equipment Vibrations online

Video

JZP-1.0B-SC and Rubber Shock Absorber for Vibration and Noise Control in Wind Loads Seismic Actions and Equipment Vibrations

Get Best Price

Good price JZP-7.0-SC1 Rubber Shock Absorber The Ideal Solution for Vibration Isolation in Electronic Equipment Manufacturing online

Video

JZP-7.0-SC1 Rubber Shock Absorber The Ideal Solution for Vibration Isolation in Electronic Equipment Manufacturing

Get Best Price

Contact Us

86-29-88292913

Contact Now

Product Description

JMZ-TK Series

The JMZ-TK series friction dampers is a new designed anti-vibration mounts, which have most characteristics of JMZ series items.

The max static load of the JMZ-TK Series friction damplers if from 2.5kg to 50kg, whichcan be specially used in many precision euipments and systerms, embedded electronics, etc.

The JMZ-TK Series friction dampers can also be used in the very narrow spaces to meet the mountable environmental requirements.This new type friction dampper is the very selection for the limits of the space under some special situations.

In addition, JMZ-TK series friction dampers have also been widely used in civilian fields. In the transportation industry, it is used in vehicle suspension systems to reduce the impact of road bumps on vehicles and improve ride comfort. In the field of marine engineering, the JMZ-TK series provides stable support for offshore platforms and ships to ensure the normal operation of equipment. In the energy field, it is used in renewable energy equipment such as wind power generation and solar power generation, improving the stability and power generation efficiency of the equipment.

Overall, the JMZ-TK series vibration isolator of Xi'an Hoan Microwave Co., Ltd. is a vibration isolation product with excellent performance and wide application. Although slightly more expensive, its excellent vibration isolation properties and wide range of applications make it the first choice for many industrial sectors. When selecting and using JMZ-TK series vibration isolators, users should fully consider their advantages and disadvantages, and choose according to their actual needs to ensure the best use effect.

Unmatched Performance and Versatility JMZ-TK1-50 Rubber Shock Absorber 0

Model	Installation dimensions(mm)			Dimensions (mm)
Model	B	M	d	A	C	Ø1	Ø2	H₁	H₂
JMZ-TK-2.5A～8A	46	6	4.1	58	20	55	22	36	3.6
JMZ-TK1-25/40/50	63	12	8.2	78	20	70	22	56	6

Technical data sheet

Model	Nominal load (N)	Load range	Natural frequency ≤(Hz)	Loading working height H₀±1(mm)	Limit displacement(mm)			Impact resistance test	Single weight ≤(g)	Service life
					Vertical		standard
					above	under
					δ1	δ2	δ3
JMZ-TK-2.5A	25	20～30	33	42	4	4	4	100g	380	10
JMZ-TK-4A	40	30～50
JMZ-TK-5A	50	40～60
JMZ-TK-6A	60	50～70
JMZ-TK-7A	70	60～80
JMZ-TK-8A	80	70～90
JMZ-TK1-25	250	200～300	20	70	7	8	7	60g	1100
JMZ-TK1-40	400	300～480
JMZ-TK1-50	500	400～600
